Monday, July 22, 2013

F1 Circuit: final renders

The run down the back straight.

Turn 6 from one of the grandstands

The run down the straight between turns 10 (chicane) and 11. This is on the exit of 10

Support pit straight, looking toward turn 4

Turn 11 and 12. One can see the hills in the background.

Saturday, July 20, 2013

F1 Circuit: the various configurations

GP circuit - 6.382km (3.595 miles)

Short circuit - 4.666km

Club circuit - sorry for the poor quality circuit line through what would be turn 4 (the chicane of the GP circuit) - it is really smooth through there

Mini circuit
Coming next are the presentation renders of my F1 circuit. I had hoped to post this a few days ago but was without an internet connection

Saturday, July 13, 2013

F1 Circuit - everything in position

Overview of the site

A shot showing turn 4 and the support pits

Turn 5

Turn 5 again

Turn 14 and 15 looking back across the circuit



So with this update, everything is in place. The next update will show the various layouts of the circuit.

Saturday, July 6, 2013

F1 Circuit - approaching completion

An overview of the site. I was unhappy with the terrain on the back straight (far left of image)

And the replacement terrain. Much nicer

A Driver level view of the back straight

The turn 5 and runoff area at the end of the back straight

Another shot, this time how it looked within Sketchup. Gives you a little insight into how I work as well ;)

The final shot of this update, looking from the carpark across turn 6 and down towards 7 and 8.
I have three more updates on this design. Next you will see the final modelling updates, revolving primarily around terrain work (and trust me, it was well worth the effort). Then I will have an update where I outline the various track layouts, before finally showing you the presentation renders I have harped on about endlessly.
